PIR

PIR1680

Advanced PIR1680 series passive infrared motion detectors exemplify NAPCO sensor technology's innovation, increasing dependability without compromising intruder catch sensitivity. For applications where animal/pet immunity is key, the PIR1680PT supports 65lb. (29kg) pet protection within its 45’ (13.7m) range. Or, the original model PIR1680, has a 50' (15.2m) range and offers nominal 20lb. (9kg) animal/rodent immunity. Outstanding false alarm rejection in both models is made possible with their advanced microprocessor that has been embedded with a library of valid and false alarm signal signatures - enabling the PIR to differentiate intruders from animals and other traditional false alarm sources. In addition to proven intruder-detection circuitry, these units also feature a built-in temperature sensor – at no additional charge - so you can provide traditional security, as well as climate security from heat and/or freeze damages, when HVAC systems fail, before pipes burst or décor, pets or perishables are ravaged by heat extremes, otherwise left unchecked.

  • 45' x 45' range
  • 65 lb pet/animal Immunity
  • Room-temp alert – temperature monitoring provides auto-alert at 40*F - 90* F
  • Look-down/creep zone
  • D.C.I.D. Technology - detect & compare imaging diagnostics for advanced false and true alarm detection
  • Active self test mode
  • Exceptional RFI-/EMI/lightning shielding of key components
  • Lens bank available, including long range, barrier, and specialty ranges
  • Wall or corner mountable
  • Tamper supervised
  • Form A relay

PIR1680PT

Standard model as above, but with 20lb. pet/animal immunity

NAPCO's dependable, affordable PIRs for residential and light commercial applications.

PIR1500/10

The tried and true PIR1500 & 1510 passive infrared motion detectors offer dependable NAPCO sensor technology optimizing intruder catch sensitivity with false alarm prevention. Both compact, unobtrusive units blend with any décor and feature a 30' x 30' (9.1m2) wide angle coverage. The PIR1510 model provides additional coverage directly beneath the sensor, using its look-down or creep-zone.

  • Economical PIR sensors with Look-Down
  • 30' x 30' broad range coverage
  • Attractive, super-compact size
  • SSP (Signal Selective Processing) for the easiest and most stable installations
  • Advanced, EZ-Aim fresnel lenses and lens bank for optimum detection performance
  • Long-range, barrier and specialty lenses are available to suit all coverage needs
  • Wall or corner mountable, with horizontal and vertical adjust
  • EMI-/RMI-/lightning protection with resilient SMD circuitry
  • Form A relay
NAPCO's most popular PIR with advanced detection technology, generous 70' x 60' range and built-in false alarm prevention features

PIR1710

The field-proven PIR1710 passive infrared motion detector offers advanced NAPCO sensor technology for increased reliability and intruder "catch" performance. With a 70' x 60' broad coverage range and look-down creep zone that provides detection coverage directly beneath the sensor, the PIR1710 offers excellent protection for virtually any application. Other enhanced false alarm prevention features include, automatic SSP Signal Selective Processing for the easiest and most stable of installations, temperature compensation, white light protection and RFI/EFI shielding, combining to make the PIR1710 a natural fit for every residential or moderate commercial application, large or small.

  • 70' x 60' broad range coverage perfect for both residential and commercial
  • Features look-down/creep zone
  • SSP (Signal Selective Processing) for the easiest and most stable of installations
  • Auto Temp compensation
  • Advanced, EZ-Aim fresnel lenses and lens bank for optimum detection performance
  • Wall or corner mountable
  • Excellent EMI-/RMI-/lightning protection with resilient SMD circuitry
  • Tamper supervised
  • Form A relay
